Angled Pencil Probes

$ 0.00 AUD

Angled Pencil Probes provide the ability to surface test where access is limited.

Request Call Back

Thank you! Your submission has been received!

Oops! Something went wrong while submitting the form.

Categories:

NDT

A variety of working length, tip angles and drops are available. Configurations produced by UniWest include bridge/reflection, absolute/differential, shielded/unshielded and in a range of frequencies.

‍

A Coil Type	B Tube Ø mm (inches)	C Angle - deg		D Drop mm (inches)			E Working Length mm (inches)				F Frequency
Bridge	3.2 (0.125)	45°	90°	2.5 (0.10)	6.4 (0.25)	12.7 (0.50)	76 (3)	102 (4)	127 (5)	152 (6)	100 kHz (100 - 500 kHz)	500 kHz (500 - 1000 kHz)	2 MHz (1- 3 MHz)
AP - (Absolute Unshielded)	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔
APS - (Absolute Shielded)	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔
APD - (Differential Unshielded)	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔
APDS - (Differential Shielded)	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔
Reflection
APSR - (Absolute Shielded)	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔		✔	✔
APDSR - (Differential Shielded	✔	✔	✔	✔	✔	✔	✔	✔	✔	✔		✔	✔

‍

All bridge configurations are fitted with Triax connectors
All reflection configurations are fitted with 4-socket Fischer connectors

‍

Part Number: [Coil Type (A)] - [Tube (inches) (B)] - [Angle (degrees) (C)] - [Drop (inches) (D)] - [Working Length (inches) (E)] - [Frequency (F)]

i.e. [APDSR-.125-45-.25-3-2] is a Differential Shield Reflection Probe with 3.2mm dia tube, 45 deg angle, 6.4mm drop, 76mm working length and 2MHz
