ECS-1

$ 0.00 AUD

The ECS-1 Mini Rotating Eddy Current Bolt Hole Scanner is specially designed for bolt hole inspections.

Request Call Back
Request Quote
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.
Categories:

The ECS-1 Mini Rotating Eddy Current Bolt Hole Scanner is specially designed for bolt hole inspections. It has the ability to synchronize and record the circumferential location and defect amplitude. Null and erase buttons are ergonomically placed by the thumb.

Scanner Specifications

Speed 1500 RPM
Frequency Range 30 KHz – 6 MHz
Probe Connector 4 pin Fischer with O Rings
Coil Type Differential & Reflection
Signal Coupling Rotary Transformer
Operating Voltage 24 VDC
On/Off Push Button
Stall Torque 0.07 Nm
Encoder RPM Control
Weight 285 g
Size 80 x 45 x 25 mm
Mounting Hand Held & Special Fixture
Null Push Button
Erase Push Button

Cable Specifications

Removable Yes
Connector 12 pin Fisher
Connector at Inst. 12 or 19 pin Fisher
Length 9.5
